Improve excavation efficiency and deliver cost savings with JetFlow 100.
The JetFlow 100 controlled flow excavation system cuts through tough soils and clays up to 100 kPa - without the requirement for additional jetting equipment.
Perfect for seabed conditions with higher soil shear strength, JetFlow 100 enhances operational efficiency and reduces deck spread complexity.
This dual-function tool also complies with DNV2.7-3 subsea lifting standards and has a compact footprint.
JetFlow 100 is suitable for a wide range of CFE applications including pipeline and cable trenching, backfilling, de-burial of cables, pipelines and subsea assets, seabed preparation and pre-installation excavations, free-span rectification, and decommissioning excavations.
Easily remove stubborn, high shear strength soils safely and quickly with JetFlow 100.
Designed, tested and built in-house by James Fisher
Advanced capabilities
- Cuts through soils/clays and provides mass flow excavation in one pass
- Next-generation hybrid subsea excavation with dual functionality performance
- Compact deck footprint in comparison with conventional CFE solutions
JetFlow 100 technical specifications
| JetFlow 100 | Mass flow nozzle | High velocity nozzle | |
| Water depth | -2 m to 305 m | ||
| Mass flow nozzle exit pressure | 88 kPa | High velocity nozzle exit pressure | 213 kPa |
| Max flow volume | 4012 l/sec | Max flow volume | 1514 l/sec |
| Max flow velocity | 10 m/sec | Max flow velocity | 14 m/sec |
| Soil strength (undrained shear strength) | Up to 50 kPa shear strength in standard format | Soil strength (undrained shear strength) | Up to 100 kPa shear strength in standard format |
| Weight | 7485 kg | ||
| Dimensions | 4.8 m x 1.9 m x 2.2 m (LxWxH) | ||
| Datasheets | View/Download - Metric | View/Download - Imperial | |
JetFlow 100 is part of James Fisher Energy’s durable, high performance range of controlled flow excavation systems, including the Twin R2000, TwinProp and TR4000, SP6000, T4000, T8000 and Twin T8000.
